UCFL 207-23 F

FL-type bearing housing units, Cast iron housing, Set screw locking spherical ball bearing, F type seal

Model exchange

OEM

Product information

Technical information

CAD

Download

Reduce

Amplify

Reduce

Amplify

Unit display /

Metric system

British system

Main dimensions and performance parameters

36.5125mm

Inside diameter

12mm

Bearing seat height

14mm

Center height

22mm

Distance from oil hole to ground

34mm

Bearing height

161mm

Overall length

130mm

Fixed hole distance

90mm

Base width

17.5mm

channel distance

42.9mm

Total width

M12

Bolt size

≈m

0.74Kg

weight

UC 207-23

Bearing Type

FL207-23

Bearing seat model

M6*1

Oil injection hole

Assembly torque

HT200

Bearing seat material

1.438in

Inside diameter

0.472in

Bearing seat height

0.551in

Center height

0.866in

Distance from oil hole to ground

1.339in

Bearing height

6.339in

Overall length

5.118in

Fixed hole distance

3.543in

Base width

0.689in

channel distance

1.689in

Total width

M12

Bolt size

≈m

0.74Kg

weight

UC 207-23

Bearing Type

FL207-23

Bearing seat model

M6*1

Oil injection hole

Assembly torque

HT200

Bearing seat material

Download this product

Download the product feature description

Your current product features

Sealing method

Lubrication method for outer ring

GV3

Locking method

Set screw locking

Tightening screw style

Assembly method

Grease

Shell Gadus S2 V100 2

Outer Ring Style

spherical surface

Layer

No processing
